This is a data sheet about dsPIC30F6011, dsPIC30F6012 dsPIC30F6013, dsPIC30F6014
The dsPIC30F6011, dsPIC30F6012, dsPIC30F6013 and dsPIC30F6014 are high‑performance 30‑bit digital signal controllers featuring low‑power Flash, wide operating voltage (2.5 V‑5.5 V) and industrial temperature ranges. They support In‑Circuit Serial Programming (ICSP) and selectable power‑management modes such as Sleep, Idle and Alternate Clock.
The datasheet provides detailed pin‑out diagrams for 64‑pin and 80‑pin TQFP packages, memory sizes, MIPS rating, and product identification codes. It also includes Microchip’s code‑protection disclaimer and worldwide sales and service contacts.
| Operating Voltage Range | 2.5 V to 5.5 V |
|---|---|
| Package | 64‑Pin TQFP (also 80‑Pin TQFP options) |
Microchip notes that code protection does not guarantee the product as “unbreakable” and that attempts to break it may violate the Digital Millennium Copyright Act.
They support In‑Circuit Serial Programming (ICSP).
The devices operate over a wide voltage range of 2.5 V to 5.5 V.
The series is offered in 64‑pin and 80‑pin TQFP packages.
