This document is a data sheet for the dsPIC30F3010/3011 high-performance digital signal controllers from Microchip Technology Inc. It provides information about the applications and features of the product.
The dsPIC30F1010/202X family are 16‑bit digital signal controllers that combine a modified Harvard‑architecture RISC CPU with DSP engine capabilities. They are offered in 28‑pin (SDIP, SOIC, QFN‑S) and 44‑pin (QFN, TQFP) packages and target industrial and extended‑temperature applications.
Key features include up to 30 MIPS processing speed, 12 KB on‑chip Flash, 512 B RAM, 10‑bit ADC with 2000 Ksps conversion rate, four PWM generators with eight outputs, and a rich set of peripherals such as UART, SPI, comparators, and multiple timers. The devices operate from 3.3 V or 5.0 V supplies and support various power‑management modes.
| Package options | 28‑pin (SDIP, SOIC, QFN‑S) and 44‑pin (QFN, TQFP) |
|---|---|
| Flash program memory | 12 KB on‑chip Flash |
| Data RAM | 512 bytes on‑chip RAM |
| Working registers | 16 × 16‑bit register array |
| Maximum CPU speed | Up to 30 MIPS |
| ADC resolution | 10‑bit |
| ADC conversion rate | 2000 Ksps |
| ADC input channels | Up to 12 channels |
| Analog comparators | Four comparators, 20 ns response time |
| PWM generators | Four generators with eight outputs |
| PWM duty‑cycle resolution | 1.1 ns at 30 MIPS |
| Dead‑time resolution | 4.2 ns at 30 MIPS |
| Phase‑shift resolution | 4.2 ns at 30 MIPS |
| Operating voltage | 3.3 V and 5.0 V |
The device can operate up to 30 MIPS.
It provides four PWM generators with a total of eight outputs.
The ADC has a 10‑bit resolution.
The controller operates from either 3.3 V or 5.0 V supplies.
