IPP90R340C3 CoolMOS™ power transistor features the lowest RON x Qg figure of merit and extreme dv/dt rating with high peak current capability. It is qualified according to JEDEC1) for target applications and compliant with RoHS. It features lead-free lead plating and offers the world's best R DS,on and ultra-low gate charge. CoolMOS™ 900V is designed for: quasi resonant flyback/forward topologies, PC silverbox and consumer applications, and industrial SMPS.
The IPP90R340C3 is a CoolMOS 900 V power transistor designed for quasi‑resonant flyback/forward topologies, PC power supplies and industrial SMPS. It offers ultra‑low gate charge, high peak current capability and a low figure‑of‑merit Ron × Qy.
Key specifications include a continuous drain current of 15 A at 25 °C, a pulsed drain current of 34 A, a breakdown voltage of 900 V, typical on‑state resistance of 0.28 Ω, and a total gate charge of 94 nC. The device is supplied in a PG‑TO220 package and operates from –55 °C to 150 °C.
It is supplied in a PG‑TO220 package.
