The TVP7002 is a triple 8-/10-bit 165-/110-MSPS video and graphics digitizer with horizontal PLL from Texas Instruments.
The TVP7002 provides a complete solution for digitizing video and graphics signals in RGB or YPbPr color spaces. It features three analog video channels, each with independent gain, offset and ADC, a fully integrated horizontal PLL for pixel‑clock generation, and support for sync‑on‑green and composite sync extraction. The device operates from 1.9 V and 3.3 V supplies and offers 8‑/10‑bit conversion at up to 165 MSPS.
The part is supplied in a 100‑pin TQFP PowerPAD package with detailed pin‑out and terminal assignments. All programming is performed via an I²C interface. Electrical specifications include supply voltage ranges, absolute‑maximum ratings, and typical power dissipation values for both normal and power‑down modes. Mechanical data and packaging dimensions are provided for PCB layout.
| Pixel clock range | 12 MHz to 165 MHz |
|---|---|
| ADC resolution | 8‑/10‑bit |
| Package type | 100‑pin TQFP PowerPAD |
The TVP7002 can generate a pixel clock up to 165 MHz.
