The guide begins with important safety notices, describing hazards such as smoke, overheating, moisture, and improper battery use, and advises users to stop operation, remove the battery, and contact an authorized service center. It also explains how to update drivers via the manufacturer’s website.
Subsequent sections cover product overview, front and rear views, button functions, and detailed instructions for inserting the battery and SD card, powering on, formatting the card, selecting language, setting date and time, adjusting image resolution, and using various shooting modes (auto, program, aperture priority, shutter priority, manual, scene, video, and playback). The manual finishes with specifications, connection methods, and accessories. This manual is written in Chinese.
| Image sensor | 1/1.8" CCD |
|---|---|
| Total pixel count | 6.30 MP |
| Effective pixel count | 5.95 MP |
| Maximum image resolution | 2816 × 2112 |
| LCD monitor | 2.0" TFT color LCD |
| Supported storage media | SD card up to 512 MB |
| Image file formats | JPEG, DCF 1.0, DPOF 1.1, EXIF 2.2, AVI, TIFF |
| Lens focal length (35 mm equivalent) | 35 mm – 105 mm |
| Optical zoom | 3× |
| Focus range | 0.08 m to ∞ (wide) / 0.09 m to ∞ (macro) |
| Shutter speed range | 8 s – 1/1500 s |
| ISO sensitivity | ISO 50 – 200 (auto) |
| Video resolution | 320 × 240 |
| Battery | Li‑ion (CNP‑60, 3.7 V, optional) |
| Dimensions (W × H × D) | 94 mm × 63 mm × 35 mm (excluding protrusions) |
| Weight | ≈180 g (without battery and SD card) |
Visit the manufacturer’s website to download and install the latest driver updates.
The camera uses an SD memory card and supports cards up to 512 MB.
