This manual covers safety information, mechanical and electrical installation, and commissioning procedures for the ABB ACS355 drive. It includes detailed wiring diagrams, cable selection guidance, and a checklist to ensure proper setup.
The document also describes start‑up methods, control panel options, programming features, and safety functions such as Safe Torque Off (STO). Appendices provide technical data, dimension drawings, and information on extension modules and safety standards.
| Frame size range | R0–R4 |
|---|---|
| Input voltage range | 200–240 V AC (1‑phase) / 380–480 V AC (3‑phase) |
| Phase configuration | 3‑phase input (code 03) |
| Output current rating | 9.7 A (example ACS355‑03E‑09A7‑4) |
| Enclosure protection | IP66/IP67 / UL Type 4x |
The ACS355 is manufactured in frame sizes R0 through R4.
Section 7 explains how to start up the drive without a control panel.
Technical data and ratings are listed in the Technical Data section on page 357 and in the Ratings table on page 358.
