This document describes the hardware information of the ACS800-37LC series drive, including appearance, installation method, electrical connection, wiring method, installation precautions, etc.
The ABB ACS800-37LC Hardware Manual provides detailed safety instructions, installation guidelines, and wiring diagrams for the 55 to 5200 kW liquid‑cooled drive. It includes sections on mechanical and electrical installation, start‑up procedures, and maintenance tasks such as fan and capacitor replacement.
Technical data, dimensions, and compliance information are presented in later chapters, along with a list of related manuals and contact details for ABB support and training resources.
| Power rating | 55 to 5200 kW |
|---|---|
| Voltage range | 380‑415 V AC |
| Voltage range | 440‑500 V AC |
| Voltage range | 525‑690 V AC |
| Degree of protection | IP54 (B055) |
| Base pressure (cooling circuit) | 100–150 kPa (recommended) |
