Azipod® CO is a new type of propulsion system developed by ABB that integrates the drive, steering and propulsion functions into a single unit, offering flexible ship design and simplified shipbuilding.
Azipod CO is an azimuthing podded propulsion system that provides high overall propulsion efficiency and fuel savings for modern, environmentally‑friendly ships. It is available in three model sizes with maximum rated propeller power up to 4.5 MW and features a pulling‑propeller design, permanent‑magnet motor, and plug‑and‑play installation.
ABB supports customers from early design through construction and operation, offering pre‑studies, supervisory services, detailed drawings, and a worldwide network of Marine Service Centers that provide maintenance, spare parts, and training.
| Power (kW) | 1300‑2300 / 2100‑3900 / 2200‑4500 |
|---|---|
| Rotation speed (RPM) | 240‑365 / 160‑280 / 120‑205 |
| Motor current (A) | 1400‑2100 / 2200‑4200 / 2300‑4800 |
| Weight (kg) | 27 000 / 47 000 / 59 000 |
| Maximum ship speed (knots) | 18 / 19 / 19‑21* |
The Azipod CO covers a power range from 1.3 MW to 4.5 MW.
Installation typically takes about half a day for the Steering module and 1‑2 days for the Propulsion module.
