The document contains information about a motherboard with the model FW82801FR. It provides details about the motherboard's connections, features, and BIOS settings.
This manual covers the features and specifications of the Topstar TMH-915GVM3 motherboard, including CPU support, memory types, expansion slots, and integrated peripherals. It also contains safety guidelines and warranty information.
Detailed sections guide users through hardware installation, BIOS configuration, driver installation, and troubleshooting, with appendices listing contact information for service centers across China. This manual is written in Chinese.
| Front Side Bus | 533 MHz / 800 MHz |
|---|---|
| Memory Type | DDR2 400/533 (non‑ECC) |
| Maximum Memory Capacity | up to 2 GB |
| Serial ATA Ports | 4 ports (max 150 MB/s) |
| PCI Express Slot | 1 × PCI‑Express 16× |
| Integrated LAN | 10/100 M adaptive Ethernet |
| Audio Output | 6‑channel sound |
Yes, it has an integrated 10/100 M adaptive Ethernet controller.
It supports DDR2 400/533 non‑ECC DIMM modules, up to a maximum of about 2 GB.
