This document is a product specification sheet for a certain brand, mainly introducing the interface types and layouts of the brand's motherboard products, as well as the functions and connection methods of each interface.
The TM-C68M/C68VM is a desktop motherboard from Topstar that uses the NVIDIA MCP68S/Y chipset. It supports AMD Socket 940 processors, DDR2 memory up to 4 GB, USB 2.0/1.1, multiple PCI‑Express and PCI slots, and offers SATA2, ATA133 and RAID0/1 storage options.
This manual covers the motherboard's features, detailed installation procedures, driver setup, BIOS settings, and includes an appendix with tools, part numbers, and contact information for Topstar service centers across China. This manual is written in Chinese.
| CPU Socket | AMD Socket 940 |
|---|---|
| USB Interfaces | USB 2.0 and USB 1.1 |
| Expansion Slots | 1 × PCIe 16x, 1 × PCIe 1x, 2 × 32‑bit PCI |
| Storage Interfaces | ATA133/100/66/33, SATA2, RAID0/1 |
The board supports AMD Socket 940 for Sempron, Athlon, X2 and FX processors.
Yes, it supports both RAID0 and RAID1.
