This is a PCB layout of a motherboard, which includes the location information of the motherboard's various interfaces and components
This manual covers the features and specifications of the Topstar T-6316M motherboard, including supported CPUs, memory types, and expansion interfaces. It also details safety precautions and warranty information.
The document includes chapters on hardware installation, driver installation, BIOS settings and upgrades, as well as an appendix with troubleshooting tips and contact information for service centers across China. This manual is written in Chinese.
| CPU Socket | LGA 775, supports Pentium4, Pentium D, Conroe series |
|---|---|
| Front Side Bus | 800/1066/1333 MHz |
| Maximum Memory | 46 GB DDR2 |
| Serial ATA Ports | 4 × Serial ATA2 (up to 300 MB/s) |
| USB 2.0 Ports | 8 × USB 2.0 (up to 480 Mb/s) |
| PCI Express Slot | PCI‑Express x16 |
| Onboard Ethernet | 1000 Mbit/s Ethernet |
| Audio Codec | HD7.1 7‑channel CODEC |
It uses an Intel LGA 775 socket and supports Pentium 4, Pentium D, and Conroe‑series processors.
The board provides eight USB 2.0 ports with a maximum transfer speed of 480 Mb/s.
The motherboard can address up to 46 GB of DDR2 memory.
It includes four Serial ATA2 ports with a maximum transfer rate of 300 MB/s.
