This is a technical manual for TM-845G, which contains information about its appearance, interfaces, and configurations.
This manual covers the features and specifications of the Topstar TM-915GVM/GLM/PLM motherboard, including supported CPUs, memory types, and expansion interfaces. It also details safety guidelines, hardware installation procedures, and the required drivers for chipset, graphics, LAN, and audio.
Additional sections describe BIOS settings and upgrades, troubleshooting tips, and a list of regional service centers with contact information. The document is intended for end‑users and system integrators who need to install, configure, and maintain the motherboard. This manual is written in Chinese.
| CPU socket | Intel LGA 775 (Pentium 4) |
|---|---|
| Front‑Side Bus | 533/800 MHz |
| Memory type | DDR333/400 (Unregistered & Non‑ECC DIMM) |
| Maximum memory | 4 GB |
| Serial ATA ports | 4 |
| USB 2.0 ports | 8 |
| Power management support | SMM, APM, ACPI |
The motherboard supports Intel LGA 775 Pentium 4 processors.
It provides eight USB 2.0 ports.
