This document is a manual for the TM-845G REV1 .0 motherboard, which describes the motherboard's connections and hardware configuration. The motherboard supports Windows XP operating system and has BIOS self-checking function.
This manual provides a complete overview of the Topstar TM-915 series motherboard, including its key features, hardware layout, and supported components. It guides users through installation steps for CPU, memory, and expansion cards, and explains BIOS configuration and upgrade procedures.
Additional sections cover driver installation for chipset, VGA, LAN, and audio, as well as a detailed appendix with troubleshooting information, contact details for service centers, and a parts list. This manual is written in Chinese.
| Chipset | Intel 915/910 series |
|---|---|
| CPU Socket | LGA 775 (Pentium 4) |
| Front Side Bus | 533 MHz / 800 MHz |
| Memory Type | DDR333 / DDR400 (non‑ECC, unregistered) |
| Maximum Memory Capacity | 26 GB |
| Serial ATA Ports | 4 ports (150 MB/s max) |
| USB Ports | 8 USB 2.0 ports |
| Power Management | Supports SMM, APM, ACPI, Wake‑on‑LAN |
It supports Intel LGA 775 sockets for Pentium 4 processors.
The motherboard provides eight USB 2.0 ports.
It accepts DDR333 and DDR400 non‑ECC, unregistered DIMMs.
Four Serial ATA ports are provided for storage devices.
