C.N70GT Ver1.5 motherboard uses AMD Socket AM2 socket, supports AMD Athlon64 FX/ Athlon64 X2/Athlon64/ Sempron series processors, supports up to DDR2 800 memory, and has 4 240-pin DIMM slots, supports 4 SATA ports and 1 IDE port, and is equipped with 1 PCI-E x16 port, 1 PCI-E x1 port and 2 PCI slots.
This manual covers the hardware specifications, supported CPUs, memory types, and expansion slots for the Colorful C.N70GT motherboard. It also details connector pinouts, front‑panel LEDs, and BIOS configuration steps.
Additional sections explain how to clear CMOS, update the BIOS in DOS mode, and provide a glossary of motherboard terminology and IRQ definitions. This manual is written in Chinese.
| CPU socket | AMD Socket AM2 |
|---|---|
| Memory type | DDR2 533/667/800 SDRAM |
| DIMM slots | 4 × 240‑pin DDR2 slots |
| PCI Express x16 slots | 1 |
| USB ports | 8 × USB 2.0 (4 internal, 4 external via cable) |
The board provides eight USB 2.0 ports – four built‑in ports and four additional ports that require a cable connection.
It uses the AMD Socket AM2 for compatible AMD processors.
