C.N70G Ver1.4 is a motherboard that supports AMD Socket AM2. It uses the NVIDIA MCP68S chipset and is compatible with AMD Athlon64 FX/ Athlon64 X2/Athlon64/ Sempron processors. The motherboard supports DDR2 533/DDR2 667/DDR2 800 memory and features interfaces such as PCIE x16, IDE, SATA, and USB. It is equipped with the nVIDIA GeForce 7025 graphics card, which supports DirectX 9.0c and Shader Model 3.0. The motherboard also has features like 8-channel audio and AC 97 digital audio.
This manual describes the hardware components and interfaces of the C.N70G Ver1.4 motherboard, including CPU socket type, memory slots, expansion slots, storage connectors and video outputs. It also covers BIOS configuration options and power‑supply design guidelines.
Detailed pin‑out tables, jumper settings, and BIOS feature descriptions are provided to help users install, configure and troubleshoot the board. The document includes diagrams for connectors such as SATA, USB, DVI, VGA, PS/2 and audio ports. This manual is written in Chinese.
| CPU Socket | AMD Socket AM2 |
|---|---|
| Supported CPUs | AMD Athlon64 FX, Athlon64 X2, Athlon64, Sempron |
| Memory Type | DDR2 533/667/800 |
| SATA Ports | 4 SATA (1 eSATA) |
| USB Ports | 8 USB 2.0 |
| Video Outputs | 1 DVI, 1 VGA |
| Audio Codec | ALC861 AC97 |
| Graphics Chipset | NVIDIA GeForce 7025 |
| Power Connectors | 24‑pin ATX, 4‑pin ATX12V, 4‑pin CPU power |
It uses an AMD Socket AM2.
The motherboard provides eight USB 2.0 ports.
One DVI and one VGA connector are available.
It supports DDR2 memory at 533, 667, and 800 MHz.
