C.N7050PV Ver1.4 is a motherboard produced by Asus. It uses the AMD Socket AM2 interface and supports AMD Athlon64 FX/ Athlon64 X2/Athlon64/ Sempron processors. The memory is 4 240-pin DIMM DDR2 800. The graphics card is nVIDIA GeForce7050SE DirectX 9.0c Shader Model 3.0. It supports PCIE x16, 1 IDE, 4 SATA2.0, 1 eSATA, 1 HDMI, 1 VGA, 1 DVI, 1 TVOUT, 8 USB, 4 CABLE.
This manual covers the hardware installation procedures for the Colorful C.N7050PV and C.MZ050PV motherboards, including mounting, power connections, and jumper settings. It also explains how to clear CMOS, update the BIOS in DOS mode, and configure integrated peripherals.
Detailed sections describe each connector type—IDE, SATA, USB, HDMI, DVI, VGA, TVOUT, and audio ports—along with supported CPUs, memory modules, and expansion slots. The document includes BIOS configuration options for power management, ACPI, and RAID settings, as well as troubleshooting tips. This manual is written in Chinese.
| CPU Socket | AMD Socket AM2 |
|---|---|
| USB Ports | 8 x USB 2.0 (4 internal, 4 external) |
