The document introduces the features and characteristics of the C.N70PV Ver1.4 motherboard, including supported processor types, memory types, interface types, etc.
The C.N70PV Ver1.4 is a Colorful motherboard built around the NVIDIA MCP68PV chipset and supports AMD Socket AM2 processors, including Athlon64 FX, Athlon64 X2, Athlon64 and Sempron CPUs. It offers four DDR2 DIMM slots for up to DDR2‑800 memory and a range of video outputs (HDMI, DVI, VGA, TVOUT).
The manual details the BIOS configuration, power‑connector pinouts, IDE/SATA interfaces, USB ports, audio circuitry, and jumper settings. It also includes diagrams for connector pin assignments and instructions for installing the board in a standard ATX case.
| CPU socket | AMD Socket AM2 |
|---|---|
| Supported CPUs | AMD Athlon64 FX, Athlon64 X2, Athlon64, Sempron |
| Chipset | NVIDIA MCP68PV |
| Integrated graphics | NVIDIA GeForce 7050SE |
| Memory type | DDR2 533/667/800 |
| Memory slots | 4 × 240‑pin DDR2 DIMM |
| PCI‑Express slots | 1 × PCI‑E x16, 1 × PCI‑E x1 |
| SATA ports | 4 × SATA2.0 |
| eSATA ports | 1 × eSATA |
| USB ports | 8 × USB 2.0/1.1 |
| Audio interface | AC97 / HD Audio |
It uses an AMD Socket AM2.
The motherboard includes eight USB 2.0/1.1 ports.
It integrates the NVIDIA GeForce 7050SE graphics chipset.
It supports DDR2 memory at 533, 667, and 800 MHz speeds.
