This document is a manual for the Colorful C.N61G Ver1.5A motherboard, providing information on hardware installation, driver installation, BIOS settings, etc.
This manual covers everything needed to set up the Colorful C.N61G Ver1.5A motherboard, including unpacking, hardware installation, driver installation, and detailed BIOS settings. It also lists the motherboard’s specifications, connector pin‑outs, and safety precautions for handling static‑sensitive components.
Additional sections provide a component layout diagram, a parts list, and technical support contact information for troubleshooting and firmware updates. This manual is written in Chinese.
| Chipset | NVIDIA MCP61P |
|---|---|
| CPU Socket | AMD Socket AM2 |
| Memory | 2 x 240‑pin DDR2 DIMM, dual‑channel DDR2 533/667/800 |
| SATA Ports | 4 x SATA2 high‑speed ports |
| USB Ports | 8 x USB 2.0 (4 expandable) |
| Audio | Integrated 6‑channel audio codec |
| Network | Integrated 10/100 Mbps Ethernet |
| VGA Port | 1 x VGA |
It provides four SATA2 high‑speed ports for storage devices.
The motherboard supports AMD Socket AM2 processors.
There are eight USB 2.0 ports, with four additional ports that can be expanded.
