The C.NC61-M2 Ver1.5 motherboard from Colorful is a motherboard that supports AMD Socket AM2. It features a MATX architecture and supports AMD Athlon 64 FX/Athlon 64/Sempron CPU with HyperTransport 1GHz. It also supports DDR2 533/DDR2 667/DDR2 800 standard memory. The motherboard uses Nvidia C51G + MCP51 chipset, supports up to 4GB of dual-channel DDR2 800 memory, and provides various expansion card slots and interfaces.
The Colorful C.NC61-M2 Ver1.5 motherboard manual provides an overview of the board’s architecture, supported CPUs, memory types, chipsets and expansion slots. It details the MATX layout, power connectors, and the included accessories.
The guide walks users through hardware configuration, BIOS setup, CMOS clearing, CPU and memory installation, and driver installation. Appendices cover BIOS flashing, troubleshooting codes, and a glossary of technical terms. This manual is written in Chinese.
| CPU Socket | AMD Socket AM2 |
|---|---|
| Chipset | Nvidia C51G + MCP51 |
| Memory Slots | 4 × 240‑pin DDR2 DIMM (max 4 GB) |
| Supported Memory Types | DDR2 533 / DDR2 667 / DDR2 800 |
| PCI Slots | 2 × standard PCI |
| IDE Ports | 2 × IDE |
| SATA Ports | 2 × SATA (RAID 0/1/JBOD) |
Set the CLR_CMOS jumper to pins 2‑3 for a few seconds, then return it to pins 1‑2 and power the system back on.
The board provides four 240‑pin DDR2 DIMM slots, supporting up to 4 GB of dual‑channel memory.
The motherboard uses an AMD Socket AM2 compatible with AMD Athlon 64 FX, Athlon 64 and Sempron processors.
It uses the Nvidia C51G + MCP51 chipset.
