C.N70GT Ver1.4 is a motherboard from C.N70 company, it is based on AMD Socket AM2 platform and supports AMD Athlon64 FX/ Athlon64 X2/Athlon64/ Sempron processors. The motherboard supports 4 DDR2 800 240-pin DIMMs and has an nVIDIA GeForce 7025 graphics card with DirectX 9.0c Shader Model 3.0 support.
This manual covers the complete setup of the Colorful C.N70GT motherboard, including CPU compatibility, memory installation, and peripheral connections. It explains the layout of components, jumper settings, and BIOS configuration for optimal performance.
Additional sections describe how to update the BIOS in DOS mode, explain the meaning of motherboard-specific abbreviations, and provide troubleshooting steps such as clearing the CMOS and handling USB or SATA issues. This manual is written in Chinese.
| CPU Socket | AMD Socket AM2 |
|---|---|
| Memory Slots | 4 x 240‑pin DIMM slots |
| Expansion Slots | 1 x PCI‑Express x16, 1 x PCI‑Express x1, 2 x PCI |
| Integrated Graphics | NVIDIA GeForce 7025 |
| USB Ports | 8 x USB 2.0/1.1 |
Short the JBAT pins 2‑3 to clear the CMOS data.
Boot into DOS, copy the BIOS files to a floppy, and run the appropriate update executable (e.g., AMI or Award) as described in Appendix C.
The board provides eight USB 2.0/1.1 ports.
It supports AMD Socket AM2 processors.
