This document is about the specification of MITSUBISHI SEMICONDUCTOR MGFS36E2527, which mainly introduces the features, applications and other information of the product.
The MGFS36E2527 is a GaAs HBT hybrid IC designed for WiMAX CPE applications. It operates in the 2.5‑2.7 GHz band and provides up to 27 dBm linear output power with 33 dB gain.
The document lists absolute maximum ratings, electrical characteristics, performance curves, application circuit details, package dimensions, and handling precautions for safe integration and reflow soldering.
| Frequency range | 2.5‑2.7 GHz |
|---|---|
| Maximum output power | 27 dBm |
The typical gain is 33 dB.
