This manual is the user manual of the WEINVIEW FR-D700 frequency converter. It mainly introduces the safety precautions, model description, surrounding environment and installation, software usage instructions, abnormal diagnosis and elimination, peripheral devices and options.
This manual covers safety precautions, product specifications, and environmental requirements for the TECO A510 series inverter. It explains panel functions, wiring diagrams, and proper grounding before energizing the unit.
Detailed sections describe fault diagnosis, motor overload protection settings, and routine inspection and maintenance procedures. An appendix provides UL‑listed motor overload protection parameters. This manual is written in Japanese.
| Power rating (200V Class) | 0.75‑2.2 kW (1‑3 HP) |
|---|---|
| Power rating (400V Class) | 0.75‑160 kW (1‑215 HP) |
| Ground resistance (200V Class) | ≤ 100 Ω |
| Ground resistance (400V Class) | ≤ 10 Ω |
Inspection and maintenance may only be performed after the power is turned off, the DC link capacitors have discharged for at least 5 minutes, and only qualified personnel should access the unit.
