Kingston KHX1600C9S3K2/8GX is a 204-pin SODIMM memory with 4GB capacity, DDR3-1600 clock frequency and 9-9-9-27 low latency timing.
The Kingston KHX1600C9S3K2/8GX kit contains two 512 MB × 64‑bit DDR3‑1600 MHz CL9 SODIMM modules (total 4 GB). Each module supports Intel® XMP profiles and operates at a standard 1.5 V JEDEC voltage. The modules are built with 204‑pin SODIMM form factor and gold‑plated contact fingers.
Key features include programmable CAS latency, on‑die calibration, bi‑directional differential data strobe, and internal self‑calibration. The kit meets JEDEC standard specifications for electrical and mechanical parameters and is tested for reliable operation within the specified temperature ranges.
| CAS Latency (CL) | 9 cycles |
|---|---|
| Row Cycle Time (tRCmin) | 49.5 ns (min.) |
| Row Active Time (tRASmin) | 36 ns (min.) |
| Operating Power | 1.410 W per module* |
| Operating Temperature | 0 °C to 85 °C |
| Storage Temperature | -55 °C to +100 °C |
| Voltage Supply | 1.5 V (JEDEC 1.425 V – 1.575 V) |
| Form Factor | 204‑pin SODIMM |
| Total Capacity | 4 GB (2 × 2 GB modules) |
The kit provides a total capacity of 4 GB, consisting of two 2 GB modules.
The modules operate at a standard JEDEC voltage of 1.5 V (range 1.425 V – 1.575 V).
Yes, each module kit supports Intel® XMP (Extreme Memory Profiles).
XMP Profile #1: DDR3‑1333 CL7‑7‑7‑20 @1.5 V; XMP Profile #2: DDR3‑1600 CL9‑9‑9‑27 @1.5 V.
