This document is a detailed configuration guide for the TL-WR1041N wireless gigabit broadband router, which describes the features and functions of the product.
This guide provides a complete overview of the TL‑WR1041N router, covering hardware description, quick installation, and detailed configuration of networking, wireless, security, and management features. It includes step‑by‑step instructions for setting up WAN/LAN ports, DHCP, wireless SSID, and advanced options such as port forwarding, VPN passthrough, and parental controls.
The manual also contains system tools for firmware upgrades, factory reset, backup/restore, and a full specifications appendix. Appendices offer FAQ troubleshooting, browser settings, and MAC address lookup to help users resolve common issues. This manual is written in Chinese.
| WAN port | 1 × 10/100/1000M auto‑MDIX RJ45 |
|---|---|
| LAN ports | 4 × 10/100/1000M auto‑MDIX RJ45 |
| Frequency range | 2.4‑2.4835 GHz |
| Maximum wireless rate (802.11n) | 300 Mbps |
| Number of antennas | 2 (omnidirectional dipole) |
| Transmit power | 20 dBm (max) |
| Operating temperature | 0 °C to 40 °C |
Use the Reset option under System Tools to restore the router to its factory settings.
