This document aims to help you use the router's functions correctly, including the router's performance characteristics and detailed descriptions of all functions. If you want to use other application-related functions in the router, you can refer to the relevant parts of this document.
This manual guides users through installing and configuring the TL‑WR740N router, covering hardware layout, quick installation steps, and detailed configuration options such as LAN/WAN settings, wireless security, DHCP, and routing features.
It also includes troubleshooting FAQs, browser setup instructions, MAC address lookup procedures, and a full specifications table for the device's wireless standards, ports, antenna, dimensions, and operating conditions. This manual is written in Chinese.
| Maximum wireless speed (11n) | 150 Mbps |
|---|---|
| Frequency range | 2.4 – 2.4835 GHz |
| LAN ports | 4 × 10/100 M Auto MDI/MDIX |
| WAN ports | 1 × 10/100 M Auto MDI/MDIX |
| Antenna type | 1 dipole omnidirectional antenna |
| Dimensions (L×W×H) | 158 mm × 120 mm × 34 mm |
| Operating temperature | 0 °C to 40 °C |
| Supported wireless security | WEP 64/128/152, WPA/WPA2, TKIP, AES |
Open the Network Connection Details page; the "Physical Address" (实际地址) shows the MAC address in the format XX‑XX‑XX‑XX‑XX‑XX.
The router supports 64/128/152‑bit WEP, WPA/WPA2, WPA‑PSK/WPA2‑PSK, TKIP and AES encryption.
The router provides four 10/100 M Ethernet LAN ports.
