This is a manual for installation and operation of BLE100 1GHz Broadband Line Extender
The BLE100 is a 1 GHz STARLINE® broadband line extender that delivers up to 34 dB of gain and meets FCC, CE and CCC approvals. This manual guides qualified personnel through installation, bench testing, alignment, and operation of the unit, including safety warnings and FCC compliance information.
The document is organized into sections covering an introduction, product overview, amplifier setup, bench testing procedures, field installation, operating tips, detailed specifications, torque specifications, and an abbreviations list. Appendices provide technical data tables and torque values for all fasteners used in the BLE100.
| Passband (S‑split) | 5 through 40 MHz |
|---|---|
| Gain, station (minimum) | 24 dB |
| Flatness | ±0.50 dB maximum |
| Power requirements (Return Amplifier) | 24 VDC, 125 mA |
| Noise figure | 6 dB |
| AC current at 90 VAC | 0.48 A |
| AC current at 60 VAC | 0.56 A |
The BLE100 is classified as a Class A digital device under Part 15 of the FCC Rules.
The Return Amplifier requires a 24 VDC supply drawing 125 mA.
A specific warning symbol is used to indicate that dangerous voltage levels are present within the equipment.
