A6S-H push button switch product information.
The A6S‑H is a surface‑mount toggle switch designed for high‑temperature soldering and reliable operation. It features a self‑cleaning double‑contact structure and is available in standard and sealed‑band packages.
The document provides mechanical dimensions, electrical ratings, environmental limits, and ordering information for the various pole configurations of the A6S‑H series. This manual is written in Chinese.
| Maximum soldering temperature | 260 °C |
|---|---|
| Insulation resistance | ≥100 MΩ |
| Contact resistance | ≤200 mΩ |
| Operating force | 0.29 N – 0.98 N |
The switch can be soldered up to 260 °C.
The insulation resistance is at least 100 MΩ.
The contact resistance is below 200 mΩ.
The actuation force ranges from 0.29 N to 0.98 N.
