This document is the dimensional drawing of A6K/A6KS small rotary toggle switches
The A6K/A6KS series are compact rotary switches offered in several mounting styles, including surface‑mount (3×3 and 5×2 terminal layouts) and through‑hole versions. Various contact configurations are identified by color‑coded rotors and selectable top‑ or side‑actuated positions.
Electrical ratings include a DC 24 V, 25 mA contact rating, insulation resistance of 10 MΩ, and an AC 250 V withstand capability. The devices operate from –30 °C to +80 °C, at 23‑95 % RH, and are rated for over 20 000 actuation cycles. Weight ranges from about 0.4 g (top‑actuated) to 0.7 g (side‑actuated). Packaging is specified in integer multiples of the unit quantity. This manual is written in Chinese.
| Rated voltage | DC24V |
|---|---|
| Contact current rating | 25 mA |
| Contact resistance | 10 MΩ |
| Insulation voltage | AC250 V (1 min) |
| Operating temperature range | -30 °C to +80 °C |
| Relative humidity range | 23 %–95 % RH |
| Mechanical life | ≥20 000 cycles |
| Weight (top‑actuated, through‑hole) | ≈0.4 g |
The series is rated at DC 24 V with a maximum contact current of 25 mA.
They are specified for operation from –30 °C up to +80 °C.
The switches are rated for at least 20 000 cycles.
