This document introduces the features and characteristics of A6D/A6DR sealed toggle switches, including ordering quantity, labeling requirements, current, weight, temperature and humidity parameters.
This manual describes the sealed‑type A6D/A6DR series switches, highlighting their high‑performance contact design, moisture resistance (IP64) and smooth operation. It includes packaging information, model variants and general precautions for safe use.
Technical data such as rated voltage, operating temperature, contact resistance, frequency range and dimensional drawings for each model (e.g., A6D‑2100, A6D‑3100) are listed, along with internal contact and PCB processing dimensions. This manual is written in Japanese.
| Rated voltage / current | DC30V 3mA, DC3.5V 10µA (minimum) |
|---|---|
| Operating temperature / humidity | -20 °C to +70 °C, ≤60 % RH |
| Contact resistance | ≤10 mΩ |
| Operating frequency | 10 Hz to 55 Hz, double amplitude 1.5 mm |
| A6D‑2100 length | 71 mm |
The switches are rated for DC30 V with a current of 3 mA, and a minimum current of DC3.5 V at 10 µA.
They operate from –20 °C to +70 °C and can be used in environments with up to 60 % relative humidity.
The contact resistance is 10 mΩ or less.
The A6D‑2100 model has a length of 71 mm.
