This document introduces a product of lever color, suitable for box-type printed circuit board plug-in terminal type A-245 E6A/E6A R. The rated value range of this product is 0.29N～9.8N, without icing and condensation.
This manual describes the A6E/A6ER push‑button switches, including their packaging specifications, rated electrical values, environmental limits, and mechanical characteristics. It also lists the foreign‑market dimensions for each model variant.
The document contains tables of part numbers, packaging units, and dimensional data, as well as important notes on ordering quantities and proper wiring practices. This manual is written in Chinese.
| Rated voltage | DC24Y |
|---|---|
| Rated current | 25 mA |
| Maximum humidity | 60 % RH |
| Contact resistance | ≥100 MΩ |
| Initial resistance | ≤200 mΩ |
The contact resistance is at least 100 MΩ.
Orders must be placed in whole packaging units.
