The small basic switch V is Omron's most popular small switch, with a variety of 10A to 21A models, which can be used for switching doors to cut off current, and has two types of thermoplastic housing and thermosetting housing. It also has heat resistance and anti-tracking features.
The Omron V series small basic switches are compact, reliable devices used for low‑current switching applications such as door control. They are offered in a variety of contact ratings from 6 A to 21 A and are available with heat‑molded or thermoset housings.
The document contains detailed electrical ratings, mechanical characteristics, terminal options, installation dimensions, and safety guidelines. It also lists the available actuator types (needle‑type, lever‑type, roller‑type) and provides wiring diagrams for the different terminal styles. This manual is written in Chinese.
| Rated voltage | AC 250 V |
|---|---|
| Maximum contact current | 21 A |
| Operating temperature range | 25 °C ~ +80 °C |
| Insulation resistance | ≥100 MΩ |
The switches are rated for AC 250 V with a maximum contact current of 21 A.
They can be used in environments from 25 °C up to +80 °C.
