G5LA is a power relay with high capacity and reliability. It complies with VDE0435, UL508, CSA22.2, and CQC certifications and offers two sealing options. The relay has high resistance to pulse voltage and leakage tracking resistance. It has low coil power consumption and can provide UL class-F insulation. The relay is suitable for loads up to 10A 250VAC and can be used for resistive loads and 1/2Hp motors. There are multiple models available to meet different requirements.
This document presents the technical specifications of Omron's G5LA series power relays, including electrical ratings such as a 10 A, 250 VAC rating and a low power consumption of 360 mW. It also lists mechanical details like a weight of 75 g and the operating temperature range.
Additional information covers performance characteristics, safety certifications (UL508, CSA22.2, VDE0435) and contact ratings for various voltage options. The datasheet is intended for engineers and designers selecting the appropriate relay for industrial control applications. This manual is written in Japanese.
| Rated current | 10 A |
|---|---|
| Rated voltage | 250 VAC |
| Power consumption | 360 mW |
| Operating temperature range | -40 °C to +85 °C |
| Weight | 75 g |
The G5LA relay is rated for 10 A at 250 VAC.
The relay consumes 360 mW of power.
It can operate from –40 °C up to +85 °C.
