This is the product manual of Delta Synchronization Gate Machine AC Drive VFD-DD series, which introduces the installation, parameter setting, fault diagnosis, troubleshooting and daily maintenance related precautions of the product.
This manual provides detailed instructions for installing, configuring and maintaining the Delta VFD002DD2 1A variable frequency drive. It includes safety warnings, wiring diagrams, parameter tables and troubleshooting guidance.
The document also lists technical specifications such as input voltage, output power and frequency range, and describes recommended storage conditions and handling precautions for the device. This manual is written in Japanese.
| Input Voltage | 1PH 200-240V 50/60Hz |
|---|---|
| Input Current | 4.9 A |
| Output Voltage | 3PH 0-240V |
| Output Current | 1.5 A |
| Power Rating | 0.25 HP (0.2 kW) |
| Frequency Range | 0.1‑120 Hz |
The drive accepts a single‑phase input of 200‑240 V at 50/60 Hz.
It is rated at 0.25 HP (0.2 kW) with a maximum output of 0.6 kVA.
The device can operate from 0.1 Hz up to 120 Hz.
Store the unit between –20 °C and +60 °C.
