This document is the installation manual for Delta 200 series AC servo drives, which introduces the features and characteristics of the product, usage precautions, installation steps, wiring instructions, etc.
The Delta VFD110CT43F21A3 AC motor drive manual begins with important safety information, warning users to disconnect power, avoid touching internal circuits, ensure proper grounding, and only allow qualified personnel to install or service the unit. It also notes precautions for long‑term storage, such as energizing the drive for 1–2 hours to reactivate electrolytic capacitors.
The document then covers detailed installation and wiring procedures, including main and control circuit terminal connections, recommended torque values for mounting screws, and optional accessories. Parameter tables, CANopen and PLC application notes, as well as troubleshooting and fault code explanations are provided to help users set up and maintain the drive correctly. This manual is written in Chinese.
| Input voltage (Light Duty) | 3PH 380‑480V 50/60Hz 25A |
|---|---|
| Input voltage (Heavy Duty) | 3PH 380‑480V 50/60Hz 19A |
| Output current (Light Duty) | 22.5A 18KVA 15HP |
| Frequency range (Light Duty) | 0‑600Hz |
| Frequency range (Heavy Duty) | 0‑300Hz |
| Maximum wire size for main terminals | 8 AWG (8.4 mm²) |
Power the drive for about 1–2 hours before first use to reactivate the electrolytic capacitors that may have degraded during storage.
The recommended torque for frame B screws is 40 kg‑cm (≈34.7 lb‑in).
