This document is the user manual of the Delta DVP-ES/EX/SS series programmable controllers, which introduces the functions and features, model descriptions, installation and wiring, commissioning, basic sequential instructions, application instructions, EX main units and I/O expansion, and abnormal phenomena judgement methods.
This manual introduces the Delta DVP‑ES/EX/SS series programmable controllers, describing the various models, their I/O capacities and optional expansion modules. It provides detailed functional specifications, special device options, and the differences between standard, mixed‑function and special‑function hosts.
Installation, wiring, test run procedures, basic sequence instructions, application commands, and guidance for using EX hosts with I/O expansion are covered. The document also includes fault diagnosis methods and information on adding new functions or commands in later firmware versions. This manual is written in Chinese.
| AC Input Voltage Range | 100~240 VAC (+10% / -15%) |
|---|---|
| I/O Points (DVP14ES00R2) | 8 inputs, 6 outputs |
| DC Power Supply (DVP14ES01T2) | DC 24 V, 5 mA Sink or Source |
The DVP14ES00R2 model provides 8 digital inputs and 6 digital outputs.
It requires an AC input voltage of 100 V to 240 V with a tolerance of +10% / -15%.
