This document provides descriptions for electrical specifications, general specifications, installation & wiring for the DVP-EH series main processing units
This manual provides the electrical specifications, installation procedures and wiring guidelines for the Omron DVP‑EH series DIDO PLC. It explains how to mount the unit in an enclosure, connect power and I/O wiring, and ensure proper grounding and protection.
The document also details input and output point configurations, power‑supply requirements, safety precautions, and recommended terminal layouts for the various model variants (08HM11N, 16HM11N, 32HM11N, etc.).
| Fuse capacity | 2 A / 250 VAC |
|---|---|
| Power consumption | 1 W / 1.5 W / 3.9 W (varies by model) |
| Insulation resistance | > 5 MΩ at 500 VDC |
| Noise immunity (ESD) | 8 kV |
| Weight (g) | 124 ~ 660 g depending on model |
No. Connecting AC mains to any input or output terminal may damage the PLC.
