The ABHSG hydraulic power unit has the features of compact design, small footprint, long service life, and low noise. It is suitable for various industrial hydraulic systems.
This manual describes the ABHSG hydraulic pump station, covering its design, reservoir options, pump types, and electrical motor configurations. It includes ordering examples, safety information, and reference standards for industrial hydraulic applications.
Key sections provide technical data such as reservoir capacities (400‑1000 L), pressure ranges, flow rates, noise levels, and component dimensions, as well as guidance for installation, commissioning, and routine maintenance of the unit.
| Reservoir volume | 400 L, 630 L, 800 L, 1000 L |
|---|---|
| Maximum operating pressure (peak) | 350 bar (A10VSO), 400 bar (A4VSO) |
| Motor voltage | 230 V / 400 V at 50 Hz, 460 V at 60 Hz |
| IP protection rating | IP55 |
The ABHSG pump station is available with reservoir volumes of 400 L, 630 L, 800 L, and 1000 L.
The peak pressure rating is 350 bar for the A10VSO pump type and 400 bar for the A4VSO type.
The unit supports three‑phase motors rated at 230 V or 400 V (50 Hz) and 460 V (60 Hz).
Noise damping walls can lower the noise pressure level by approximately 10 to 15 dB(A).
