The TP-LINK TL-SL3226P switch is fully compliant with the IEEE 802.3 Ethernet standard, and its standard rack-mounted structure design and intelligent configuration management settings can provide an ideal networking solution for building small, medium and large networks, especially intelligent community broadband access.
The TL‑SL3226P is a 24‑port gigabit network switch with two expandable module slots, fully compliant with IEEE 802.3 Ethernet standards. It offers multiple management methods—including SNMP, Web, Telnet, and out‑of‑band RS‑232—and supports VLAN, IGMP Snooping, 802.1X authentication, and Spanning Tree protocols.
The device includes 24 10/100 Mbps RJ‑45 ports, two independent module bays for 100 M/1000 M optical or UTP modules, and a console port. Physical dimensions are 440 mm × 260 mm × 44 mm, power consumption up to 25 W, and it operates in temperatures from 0 °C to 40 °C. This manual is written in Chinese.
| RJ‑45 ports | 24 |
|---|---|
| Expansion slots | 2 |
| Supported module types | 100M/1000M optical and UTP modules |
| Maximum power consumption | 25 W |
| Input voltage range | 110‑260 VAC, 50/60 Hz |
| Dimensions (L × W × H) | 440 mm × 260 mm × 44 mm |
| Operating temperature | 0 °C to 40 °C |
| Storage temperature | -40 °C to 70 °C |
| MAC address table size | 6 K |
| Maximum VLANs | 256 |
| Maximum Trunks | 7 |
| SNMP versions supported | v1, v2c |
The switch provides 24 10/100 Mbps RJ‑45 ports.
It supports SNMP, Web browser, Telnet, and out‑of‑band RS‑232 management.
The device consumes up to 25 W of power.
