Key facts
- Brand
- Yamaha
- Model
- DME8O-C
- Industry
- Electronics
- Documents
- 5
- Languages
- EN · ZH
- Last added
- 2012-06-12
Start here
Yamaha DME8i-C/DME8o-C/DME4io-C Digital Mixing Engine Satellite User Manual
This document provides instructions for the Yamaha DME8i-C, DME8o-C, and DME4io-C Digital Mixing Engine Satellite. It details safety precautions, system configuration using DME Designer software, CobraNet setup, MIDI data flow, and network connectivity via Ethernet.
The guide explains how to connect the satellite units to a main engine (DME64N or similar) and configure them for audio processing. Topics include power supply requirements, input/output connections, USB programming, and troubleshooting common issues related to signal flow and software setup.
All Yamaha DME8O-C documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What type of Ethernet cable should be used for a direct connection between two devices?
Cross cables should be used for direct connection between two devices.
From: YAMAHA Errata DME8i-C/DME8o-C/DME4io-C owner's manual P.17 MY16-CII owner's manual P.8
What is required to connect three or more devices in a CobraNet network?
Hubs and straight cables are required to connect 3 or more devices.
From: YAMAHA Errata DME8i-C/DME8o-C/DME4io-C owner's manual P.17 MY16-CII owner's manual P.8
What software is required to configure the DME Satellite?
The manual references using 'DME Designer' software for configuration and setup of the satellite units.
From: Yamaha DME8i-C/DME8o-C/DME4io-C Digital Mixing Engine Satellite User Manual
How do I connect the satellite to the main engine?
The units are designed to work with a main engine such as the DME64N, DME24N, or other compatible models listed in the manual.
From: Yamaha DME8i-C/DME8o-C/DME4io-C Digital Mixing Engine Satellite User Manual
What is the purpose of the lightning flash symbol on the unit?
The symbol alerts the user to the presence of uninsulated dangerous voltage within the product's enclosure that may constitute a risk of electric shock.
From: Yamaha DME8i-C/DME8o-C/DME4io-C Digital Mixing Engine Satellite Owner's Manual
What should a user do if the power cord or plug is damaged?
The user must refer all servicing to qualified service personnel when the apparatus has been damaged in any way, such as a power-supply cord or plug being damaged.
From: Yamaha DME8i-C/DME8o-C/DME4io-C Digital Mixing Engine Satellite Owner's Manual
