Start here
Teridian 71M6513/71M6513H Demo Board Quick Start Guide
The guide introduces the Teridian 71M6513/71M6513H Demo Board, a development platform that includes the 71M6513 or 71M6513H IC, peripheral circuitry, and a Debug Board for RS‑232 PC connection. It describes the kit contents, safety precautions, and how to load custom firmware via the emulator or Flash Programmer Module.
Safety notes stress extreme caution when connecting live voltages and handling the board due to its ESD sensitivity. The document also provides test‑setup wiring, power‑supply requirements, and contact information for technical support.
Teridian 71M6513H specifications
| Energy per pulse (Kh) | 3.2 Wh/pulse (CT 2,000:1) |
|---|---|
| Power supply input | 100 to 240 VAC, 1 A DC output |
| Wall transformer | 2 × 5 VDC/1,000 mA universal transformer |
| Serial cable | DB9 male/female, 2 m |
| Integrated circuit | 71M6513 or 71M6513H IC |
Source: Teridian 71M6513/71M6513H Demo Board Quick Start Guide
All Teridian 71M6513H documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
The shortest path to a working setup, usually only a few pages.
Questions answered in these manuals
How can I load custom firmware onto the demo board?
Custom applications can be downloaded through the emulator (ICE) port or using the Flash Programmer Module (TFP‑1).
From: Teridian 71M6513/71M6513H Demo Board Quick Start Guide
What ADC resolution does the 71M6513 support?
The device can operate with either 21‑bit or 22‑bit resolution, selected via the FIR_LEN register.
From: Teridian 71M6513/71M6513H 3-Phase Energy Meter IC Datasheet
What is the voltage reference accuracy for the high‑accuracy version?
The high‑accuracy part (71M6513H) offers a voltage reference temperature coefficient of less than 40 ppm/°C.
From: Teridian 71M6513/71M6513H 3-Phase Energy Meter IC Datasheet
