Key facts
- Brand
- Lenovo
- Model
- MANUALV1
- Category
- Motherboard
- Industry
- Computers
- Documents
- 5
- Languages
- ZH
- Last added
- 2012-03-28
Start here
LENOVO ThinkServer T350 Servers Computer user manualv1.0
This manual provides safety warnings, ESD protection guidelines, and proper handling procedures for the ThinkServer T350. It explains power requirements, grounding, and environmental considerations to prevent injury and equipment damage.
The document also details chassis features, component installation, BIOS settings, and network wake‑up configuration, offering step‑by‑step instructions for system setup and maintenance. This manual is written in Chinese.
Lenovo MANUALV1 specifications
| Chipset | Intel 810 series |
|---|---|
| Form factor | Micro‑ATX |
| Keyboard power‑on | Supported |
Source: LENOVO MS6137EL2A REV 2.1A motherboard Manualv1.0(1)(1)
All Lenovo MANUALV1 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What safety steps must be taken before handling server components?
Wear an ESD wrist strap, connect it to the server chassis, and always touch the metal part of the chassis before handling any component.
From: LENOVO ThinkServer T350 Servers Computer user manualv1.0
What is required for network wake‑on‑LAN to work?
The network card must be connected to the motherboard via the appropriate pins, including the PME (Power Management Event) pin, and the BIOS must have Wake‑On‑LAN enabled.
From: LENOVO ThinkServer T350 Servers Computer user manualv1.0
How do I clear the CMOS?
Short pins 1‑2 of jumper JBAT1 to clear the CMOS settings.
From: LENOVO MS6137EL2A REV 2.1A motherboard Manualv1.0(1)(1)
How do I clear the CMOS settings?
Short pins 1‑2 of jumper JBAT1 to clear the CMOS.
How do I save BIOS changes and exit?
Select “Save to CMOS and Exit (Y/N)”, press Y then Enter; the system will restart with the new settings.
