Lenovo E75 Display User Manual
User Manual 18 pages · 5.2 MB · EN
This manual provides instructions for setting up and using the Lenovo E75 display. It includes safety guidelines, power connection details, and step‑by‑step procedures for adjusting on‑screen display (OSD) settings such as brightness and contrast.
Additional sections cover driver installation for Windows Vista, basic troubleshooting tips, and warranty information to help users maintain optimal performance of the monitor.
Lenovo E75 specifications
| Chipset | Intel E7505 Memory Controller Hub |
|---|---|
| ICH | Intel 82801DB |
| Memory Slots | 4 x 184‑pin DDR, dual‑channel Registered ECC DDR266 |
| Network Controller | Broadcom BCMS5703CIKHB Gigabit Ethernet |
| SCSI Controller | LSI 53C1030 Ultra320 |
All Lenovo E75 documents by type
User Manual 3
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How do I clear the CMOS on this motherboard?
Power off the system, remove the power connector, then short pins 2 and 3 of the BAT1 jumper.
What type of memory can be installed?
The board accepts four 184‑pin DDR modules, supporting dual‑channel Registered ECC DDR266 memory.
