Key facts
- Brand
- FUJI
- Model
- J120
- Category
- Other Electronics
- Documents
- 3
- Languages
- EN
- Last added
- 2012-05-02
Start here
FUJI J100/J120/J110W/J150Wcamera user manual
The Owner's Manual provides safety instructions, installation guidance, and operating procedures for the FinePix J100, J110w, J120, and J150w digital cameras. It includes warnings about water, electricity, and proper handling to prevent fire or electric shock.
The guide also details battery usage, charging procedures, and care for accessories such as the AC adapter and BC‑45A charger. Information on disposal, regulatory compliance, and copyright notices are included to help users maintain the camera safely and responsibly.
FUJI J120 specifications
| Collector‑Emitter voltage (VCES) | 1200 V |
|---|---|
| Gate‑Emitter voltage (VGES) | +20 V |
| Maximum junction temperature (Tj) | +150 °C |
Source: Fuji Electric 2MBI450U4J-120-50 IGBT Module Specification Handbook
All FUJI J120 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the recommended torque for mounting the module on a heat sink?
The final torque should be the full specified value of 3.5 Nm.
From: Fuji Electric 2MBI450U4J-120-50 IGBT Module Specification Handbook
What torque is recommended for PCB mounting of the module?
Use a tightening torque of 0.4 to 0.6 Nm for the PCB screws.
From: Fuji Electric 2MBI450U4J-120-50 IGBT Module Specification Handbook
What is the maximum collector‑emitter voltage rating?
The module is rated for a collector‑emitter voltage of 1200 V.
What torque should be applied when mounting the module on a heat sink?
Initial mounting uses about one‑third of the specified torque, and the final torque should be 3.5 Nm.
How many times can the battery be recharged?
The battery can be recharged about 300 times under normal temperature conditions.
Can I use this camera in a hospital or on an aircraft?
The camera may interfere with hospital or aviation equipment; you should consult hospital or airline staff before using it in those environments.
