Installation guide for the TP-LINK YLAP530G wireless ceiling access point, covering hardware features, mounting, and network configuration.
This guide provides step‑by‑step instructions for installing the TP‑LINK YLAP530G wireless ceiling AP. It explains the hardware characteristics, required tools, safety precautions, and the procedures for mounting the device on a ceiling or wall.
The manual is organized into sections on product introduction, installation preparation, mounting methods (ceiling and wall), network configuration for FAT and FIT modes, and includes appendices with the warranty card and toxic‑substances statement. This manual is written in Chinese.
| Power options | Standard PoE (IEEE 802.3at/af) or 12 V DC (≥1 A) |
|---|---|
| Operating temperature | 0 °C ~ 40 °C |
| Storage temperature | -40 °C ~ 70 °C |
| Mounting options | Ceiling or wall installation |
| Interfaces | 1 × LAN port, 1 × DC power jack, reset button, "易展" button, FAT/FIT mode switch |
While the AP is powered, press and hold the RESET button until the system indicator flashes, then release; the AP will automatically restore factory defaults and reboot.
The AP can be powered via standard PoE (IEEE 802.3at/af) or by connecting a 12 V DC power adapter (minimum 1 A).
