Installation guide for the TP-LINK TL-XAP3007GC-PoE/DC wireless ceiling access point, covering hardware features, setup steps, and network configuration.
The TL-XAP3007GC-PoE/DC is a TP‑LINK wireless ceiling access point designed for indoor enterprise environments such as hotels, restaurants, and malls. It supports both PoE (IEEE 802.3af/at) and 12 V DC power, and can operate in FAT (stand‑alone) or FIT (controller‑managed) mode.
This manual provides a product overview, lists required tools and accessories, details the installation procedure, and explains network configuration for both FAT and FIT modes. Appendices include warranty information and hazardous‑substance declarations. This manual is written in Chinese.
| Power Supply Options | IEEE 802.3af/at PoE or 12 V DC 2.0 A adapter |
|---|---|
| DC Power Adapter Requirement | 12 V DC 2.0 A, 5.5 mm×2.1 mm connector |
| Network Interface | WAN/LAN (PoE) port supporting IEEE 802.3af/at |
Press and hold the RESET button while the AP is powered on until the system indicator flashes, then release; the AP will reboot with factory settings.
The device can be powered via IEEE 802.3af/at PoE or by a 12 V DC 2.0 A external adapter.
Use the FAT/FIT mode switch on the unit; set to FIT for controller‑managed operation, or to FAT for standalone management. The AP will restart automatically after switching.
