Installation guide for TP-LINK PoE·AC integrated VPN routers covering hardware features, setup steps, connections, configuration and cloud management.
The TP-LINK PoE·AC integrated VPN routers are designed for small‑business and office environments, combining PoE power delivery with an AC wireless controller. Models TL‑R479P‑AC, TL‑R473GP‑AC, TL‑R479GP‑AC, TL‑R489GP‑AC and TL‑R479GPE‑AC support VPN, firewall, bandwidth control and cloud management.
This manual provides a product overview, a step‑by‑step installation procedure, hardware connection details, configuration instructions, cloud‑management setup, a troubleshooting appendix and a full technical‑specifications table. This manual is written in Chinese.
| WAN ports | 1FE (TL‑R479P‑AC) / 1GE (others) |
|---|---|
| Maximum PoE output power | 54W (up to 120W for TL‑R489GP‑AC) |
| PoE standard | IEEE 802.3af/at |
| Dimensions (L×W×H) | 226×131×35 mm (TL‑R479P‑AC) / 250×158×44 mm (TL‑R473GP‑AC) |
After resetting, the default management address is tplogin.cn.
The router complies with IEEE 802.3af/at PoE standards.
The router operates from 0 °C to 40 °C and can be stored from –40 °C to 70 °C.
