The ICT-6D is a desktop digital IC tester that quickly evaluates ICs with auto‑search, loop testing, and supports multiple voltage levels.
The ICT-6D digital IC tester is designed for fast, accurate evaluation of digital IC components. It features an auto‑search function that tests ICs without any button presses, a LOOP mode for continuous testing, and audible alerts to indicate results. The unit includes a 16‑character back‑lit LCD and a compact desktop design.
Key specifications include a 28‑pin test socket supporting over 1,800 part numbers, test voltages of 2.5 V, 3.0 V, 3.3 V and 5 V, and a rapid 0.6 second average test time per IC. The device operates from AC 110‑220 V, measures 33.5 cm × 30 cm × 10.5 cm, and weighs 1.25 kg. This manual is written in Chinese.
| Test Voltage | 2.5 V / 3.0 V / 3.3 V / 5 V DC |
|---|---|
| Display | 16‑character LCD with backlight |
| Power Supply | AC 110 V ~ AC 220 V |
| Size | 33.5 cm × 30 cm × 10.5 cm |
| Function Keys | 6 function keys (TYPE, BUZZER, LOOP, AUTO, GO, <-, Voltage) and 10 numeric keys (0‑9) |
It tests each IC in an average of 0.6 seconds.
It supports test voltages of 2.5 V, 3.0 V, 3.3 V and 5 V DC.
The AUTO function performs automatic search testing, and the LOOP function continuously tests the same IC while providing audible alerts.
