Panasonic WJ-HD309A/WJ-HD316A Digital Disk Recorder Operating Instructions

This manual details the operating methods of the WJ-HD309A/WJ-HD316A digital disk recorders.

Brand: Panasonic
Category: Network Switches
Document type: User Manual
Language: English
Pages: 182
File format: PDF
File size: 5 MB
Published: 08 August, 2012
Updated: 30 September, 2023
Model: WJ-HD309A
MD5 checksum: 9D1D549D3848372392B18F39B6FDE86D
PDF: Panasonic WJ-HD309A/WJ-HD316A Digital Disk Recorder Operating Instructions PDF

About this manual

This document provides operating instructions for the Panasonic WJ-HD309A and WJ-HD316A digital disk recorders. It details how to connect and operate the unit using the front panel buttons. The manual also includes important safety information, such as warnings regarding electric shock, moisture, and proper ventilation.

What's inside

Important Safety Instructions
Precautions
Built-in Backup Battery
Cooling Fan
Cleaning
Built-in Hard Disk Drives
Placement
Condensation

Specifications

Operating Temperature	+5°C - +45°C (41°F - 113°F)
Recommended Operating Temperature	+20°C - +30°C (68°F - 86°F)
Humidity Limit	below 85 %
Input Power Source	120 V AC 60 Hz
Battery Life	approximately 5 years
Hard Disk Drive Vibration Warning	Do not move just after turnind their power on or off

Frequently asked questions

How long should the built-in backup battery be charged before first use?

You should charge the builtin backup battery by turning on the power for 48 hours or more.

What is the recommended temperature range for optimal performance?

It is recommended to use the appliance at temperatures within +20°C - +30°C (68°F - 86°F).

Can I move the hard disk drives immediately after turning the power on or off?

No, you should not move them just after turning the power on or off for around 30 seconds.
