Describes the assembly and setup steps of the WT48 scanner
The Image Access WideTEK 42/48 is a high-speed flatbed scanner designed for efficient document scanning with an integrated web-based user interface. This Setup and Assembly Manual guides technical staff through the mechanical installation of the floor stand, power connection, and initial software configuration required to operate the device.
The guide covers essential procedures including IP address setup via the touch panel, optical adjustments such as white balance, firmware updates, and option installations. It also details cleaning protocols for transport drums and glass plates, network analysis methods, recovery functions to factory defaults, and provides a comprehensive list of technical specifications regarding dimensions, electrical requirements, and sensor capabilities.
| Maximum Document Width | 50 inch / 1270 mm |
|---|---|
| Scan Width (Minimum) | 42 inch / 1067 mm |
| Scan Width (Maximum) | 48 inch / 1220 mm |
| Optical Resolution | 600 dpi |
| Sensor Type | Four color CCDs, encapsulated and dust-proof |
| Internal Grayscale Resolution | 12bit grayscale |
| Internal Color Resolution | 36bit color |
| Sensor Resolution | 91.200 pixels |
| Operating Temperature | +5 to +40° Celsius |
| Power Consumption (Scanning) | 210W |
It is recommended to always use the scanner in combination with the floor stand.
You can perform a recovery function by following the specific steps outlined in the manual, but important notes should be read before proceeding.
The device supports 1bit Black/White, 8bit Grayscale, and 24bit Color, 8bit indexed modes.
