Extech SDL800 Digital Vibration Meter/Datalogger is a multi-function instrument for measuring vibration amplitude, velocity and acceleration. It has a wide frequency range (10Hz to 1kHz), high accuracy (±(5% + 2 digits)), and easy data transfer to PC for analysis with SD card storage.
The Extech SDL800 is a Vibration Meter/Datalogger designed to test vibration levels on motors, bearings, fans, pumps, and other rotating machinery. It features a wide frequency range of 10Hz to 1kHz and supports RMS, Peak Value, or Max Hold measurement modes. The device includes a remote vibration sensor with a magnetic adapter on a 47.2" cable for flexible measurement.
| Frequency Range | 10Hz to 1kHz |
|---|---|
| Basic Accuracy | ±(5% + 2 digits) |
| Measurement Modes | RMS, Peak Value or Max Hold |
| Sampling Rate | 1 to 3600 seconds |
| Memory Capacity | 20,000K data records using 2G SD card |
| Dimensions | 7.2 x 2.9 x 1.9" (182 x 73 x 47.5mm) |
| Weight | 21.1oz (599g) |
The device has a wide frequency range of 10Hz to 1kHz.
The meter supports RMS, Peak Value, or Max Hold measurement modes.
Data is saved on an SD card in Excel® format for easy transfer to a PC.
